M35 Power Series

    The M35 series of waterproof Power connectors from GT Contact are ruggedly built with push-lock type couplings (coupling tools also available) and sealed to IP67. They can be used in-line with cable to cable connections or for cable to panel-mount connections, with a choice of either end being a male or female connection. Designed for panel cut-outs of 35.2mm with a 3 pin gold-plated contacts with screw style terminations. The M35 series is perfect for applications such as Inverters, Outdoor Motors, HVAC, Outdoor Lighting, LED Screens, Outdoor Security Systems, Solar Energy, Medical Devices, Marine Equipment and Industrial Control Systems.

    M35 Power Series — image 1 M35 Power Series — image 2 M35 Power Series — image 3 M35 Power Series — image 4
    GT Connect logo

    Product Variations

    4 results
    Product Code Compliance Number of Pins IP Rating Current Rating A Voltage Rating VAC Gender Termination Style Mating Style Panel Cut out size mm Housing Material Housing Style
    GT1E1400-42030 RoHS 3 IP67 41 600 Female Screw Push-Lock 35 Plastic Rear-nut Panel Mount
    GT1E1401-42030 RoHS 3 IP67 41 600 Male Screw Push-Lock 35 Plastic Rear-nut Panel Mount
    GT1E1410-42033 RoHS 3 IP67 41 600 Female Screw Push-Lock - Plastic Cable Mount
    GT1E1411-42033 RoHS 3 IP67 41 600 Male Screw Push-Lock - Plastic Cable Mount
